 SAEJ2044 9.49mm  Nylon adblue Quick Connector for Scania/Volvo/Renault Truck SCR System

Working pressure: 5bar (72psi) Working pressure in Vacuum: -0.55bar (-7.2psi) Working temperature: -40-115℃ , short time 150℃
Availability:
Quantity:
  • Standards Rubber

  • 3917290000



SAEJ2044 9.49mm  Nylon Quick Connector for Scania/Volvo/Renault Truck SCR System


1 DESIGN OF  QUICK CONNECTOR


Innovative, secure and quick, Our quick connect fittings made of synthetic material are high resistance to the corrosive Adblue urea solution. It is easy to assemble. We offer the idea means of connection . These quick connectors are specially suited to being matched up with the automotive pipe system the design and production of quick connector are strictly fits with SAE J2044-2009 Quick Connect coupling  specification for Adblue urea fluid,no degradation of Adblue . If the product does not meet customer needs , we can design and manufacture according to customers requirements .Plug-in and sel-locking structure enables connect and disconnect more quick  and easier . The space required for the operation is only the width of a finger on both sides . These features ensure quicker connector  can be high-density arrangement and an increase in customer design flexibility,One manifold size per diameter,the smart and simple solution ensuring proper temperature management of the fluid thanks to its auto-regulated power,Complete portfolio thanks to a wide range of design,angles,and diameters answering any application or assembly situation.


 scr quick connector (18)

scr quick connector (16)_副本


2 SECURITY OF QUICK CONNECTOR


 Quick connector with double sealing rings radial sealing structure , modified rubber o-rings used , mainly for fluid The physics  chemistry , custom , anti-aging , corrosion , and swelling ; outer o-rings are separated by the intermediate spacer ring . Coresponding  space on the two sealing ring , rubber substrate bonding does not occur the outer synthetic rubber o-rings used , Increased  mechanical properties. preventing air aging . Sealing ring and spacer ring through the outer ring of elastic clamping device securely fastened in Shell will not result in phenomena such as ring falls of , and shift . Great seal security is guaranteed


design of quick connector


3. MATERIAL


Parts

Material

Supplier

Application

Body

PA12 GF30

ARKEMA

EVONIK

Fuel

PA66 GF30/35

BASF

DUPONT

Fuel Steam

PA6/6T GF25

BASF


HT Fuel

PA9T GF30

KURARAY


HT Fuel

Locking Spring

PA11

ARKEMA


Fuel

PA66

BASF

DUPONT

Fuel, Steam

Securing Ring

PA12 GF30

ARKEMA

EVONIK

Fuel,Steam,Urea,A/C ,          Power Steering System

PA6/6T GF30

BASF


HT Fuel

PA66GF 30/35

BASF


Fuel Steam

O Ring

FKM/FVMQ/

 HNBR/AEM

HUTCHINS ON

GMORS

Fuel,Steam,Urea,A/C           Power Steering System


quick connector for SCR lines
